TECH INFORMATION
- Microphone / Line Input.
- Frequency Response: 20Hz to 22 kHz +/-2dB
- Microphone Input Impedance: 3.9 kΩ.
- Line Input Impedance: 10 kΩ.
- Microphone Input S/N ratio: >100 dBu.
- Microphone Input s: Electronically Balanced / Discrete Input Configuration.
- Line Inputs: Electronically Balanced.
- Inputs Distortion (THD&N): 0.02% At 1 kHz.
- Channel EQ: High shelving +/-15dB @12 kHz. / Low shelving +/- 15dB @80 kHz.
- Aux Send: 1 with paths for DSP internal section, external DSP section and Monitor Out.
- DSP Section: 24-bit HALL,ROOM, VOCAL,PLATE,STEREO DELAY, REV + DELAY, and REV+CHORUS combinations.
- Master Section: Master Level knob, 4 LEDs level meter DSP Return level.
